Electric-Powered Multifunctional Hospital Operating Table

Hospital Electric Motor Multifunction Operating Table is a crucial device designed specifically for operating rooms in medical institutions. It is powered by electricity and capable of performing multiple functions. For example, the height of the tabletop, the tilt angle, and the positions of the headboard and leg board can all be adjusted flexibly to meet the requirements of different surgical postures, facilitating precise operations by doctors. It provides a stable, comfortable and precisely controlled operating platform for the smooth progress of surgeries, ensuring the safety and comfort of patients during the surgical process.

Description
Inquiry

Product Information

Model:electric operation table ECO series
Certification:CE
Packaging Details:standard exporting packaging
Brand Name:XINGMAOTONG
Trademark:XINGMAOTONG
Place of Origin:China
Warranty:1 year
Length: 2100mm
Width: :500 mm
Table height::750 ~ 1000mm
Forward tilt:25
backward tilt::25°
Left and right tilt:15°
head plate: up:45
head plate: down:90°
Platform Horizontal movement:400mm

Description

Medical Stainless Steel Electric Ophthalmic Operation Table with C-arm Fluoroscopy

XMT005A Electric Operation Table is used for the various operating room of the hospital.

Advantages of XMT005A Electric Operation Table:

1. The translational amount of the table top reaches 400mm. Installed C-arm fluoroscopy.

2, the head and leg plates can be disassembled, and can be equipped with orthopedic traction frame, head frame, etc. for lower limb orthopedic surgery and brain surgery.

3. Equipped with a built-in emergency power supply, the emergency power supply can automatically charge.

4. Air springs are used for folding back and leg plates.

5. The front of the table is tilted backward, left and right, up and down, and moved forward and backward.

6. All realized by motors and operated by buttons.

7. XMT005A adopts 24V DC voltage, which is safe and reliable.

Specification Of XMT005A Electric Operation Table:

Length:	2100mm	Width:	500 mm
Table height:	750 ~ 1000mm	Stroke:	≥ 250mm free to lift, lock
Forward tilt:	≥25°	backward tilt:	≥25°
Left and right tilt:	≥15°	head plate:	up ≥45°
head plate:	down ≥90°	back plate:	≥45°
Waist rise lifting:	≥80mm	Platform Horizontal movement:	≥400mm
Power:	AC 220V ± 10%, 50HZ	Safe working load:	≥135kg
Leg plate:	down ≥90°	Leg plate spilt:	≥90° detachable
Foot plate can be 90° on the leg plate and can be removed.
